LG Oven & Range Error Codes: Complete List with Fixes

LG ovens and ranges — including ProBake Convection, EasyClean, InstaView, and slide-in models — use temperature sensors, door lock mechanisms, and communication buses between control boards to maintain safe and accurate cooking. When any component reads outside safe parameters, the oven displays an F-code error on the control panel. This guide covers every LG oven error code with real part numbers, safety warnings for high-temperature faults, and step-by-step repair procedures.

How LG Oven Error Codes Work

LG ovens display error codes as "F" followed by a number (F0, F1, F2, etc.). Some codes are safety-critical — F1 (relay protection loss) and F2 (over-temperature) require the oven to be immediately disconnected from power. On double oven and combination units, the code may include a prefix indicating upper or lower cavity.

Before troubleshooting:

1. Turn off the oven circuit breaker — not just the oven's power button. Many F-codes indicate potential safety issues that require full disconnection.
2. Wait for the oven cavity to cool completely before opening panels.
3. Write down the exact F-code. On double ovens, note which cavity displayed it.

LG oven error codes do not clear with a simple power cycle the way washer or dryer codes do. The underlying component must be repaired or replaced first.

F0 — Shorted CLEAR/OFF Key

The control board detects a continuous signal from the CLEAR/OFF button on the membrane keypad, as if it is being held down permanently.

Common causes:

• Membrane keypad short from heat and steam degradation (part EBR84433510)
• Keypad bubbling, peeling, or moisture trapped behind the membrane
• Ribbon cable connection corroded between keypad and control board (part EAD63928905)
• Steam migration behind the control panel after self-clean cycles on ProBake and InstaView models
• Control board input circuit failure (part EBR84433508)

How to fix:

1. Unplug the oven or turn off the circuit breaker for 5 minutes, then restore power. Membrane keypad shorts can clear after a full power reset.
2. Inspect the keypad membrane for bubbling, peeling, or visible moisture. Heat and steam from cooking degrade the membrane over time.
3. Disconnect the keypad ribbon cable from the control board and power the unit on. If F0 clears, the keypad needs replacement. If F0 remains, the control board is at fault.
4. On ProBake and InstaView ovens, F0 commonly follows self-clean cycles because steam migrates behind the control panel. Allow the panel area to dry for 24 hours before condemning the keypad.
5. On combination microwave/wall oven units, verify you are troubleshooting the correct keypad (upper vs. lower).

Part cost: Keypad membrane assembly (EBR84433510) $60–$120. Control board (EBR84433508) $120–$200. Professional repair: $150–$320.

F1 — Safety Relay Protection Loss (CRITICAL)

F1 indicates the control board has lost the ability to monitor or control the heating relay. The oven may heat without user input. This is the most safety-critical LG oven error.

Common causes:

• Control board relay circuit failure (part EBR84433508 — Oven Control Board)
• Relay stuck closed, causing uncontrolled heating
• Keypad shorted key variant sending continuous bake signal
• Gas safety valve relay monitoring lost on gas models

How to fix:

1. Turn off the oven circuit breaker immediately. F1 is a safety relay failure — the oven must not be operated.
2. After 10 minutes, restore power and observe whether the oven attempts to heat without any button input. If it heats on its own, the relay is stuck closed and the unit is unsafe until repaired.
3. Disconnect the bake and broil element wire leads at the control board before restoring power to safely test the board response.
4. If F1 persists with heating elements disconnected, the control board relay circuit has failed and the board must be replaced.
5. On gas models, F1 may indicate the gas safety valve relay circuit has lost monitoring capability. Close the gas supply valve in addition to turning off the breaker.

Part cost: Oven control board (EBR84433508) $120–$200. Keypad assembly (EBR84433510) $60–$120 if shorted key variant. Professional repair: $200–$380.

F2 — Door Latch / Oven Over-Temperature

F2 has two variants: over-temperature (the oven exceeded safe limits during normal operation) and door latch failure (the lock did not engage before self-clean temperatures were reached).

Common causes:

• Temperature sensor (RTD probe) failure or disconnection (part MEE62002708)
• Door latch motor failure during self-clean initiation (part ABA74268301)
• Control board relay stuck, causing continuous heating
• ProBake Convection fan stopped, causing localized sensor overheating

How to fix:

1. If the oven is excessively hot, turn off the circuit breaker and allow it to cool completely before opening the door. Do not open the door if the oven is above 500°F.
2. Check the oven temperature sensor (RTD probe) mounted inside the oven cavity at the top rear. Test resistance: approximately 1,080 ohms at room temperature (77°F). The RTD resistance increases linearly — approximately 1,300 ohms at 350°F, 1,500 ohms at 550°F.
3. Inspect the door latch mechanism. If F2 appeared during self-clean, the latch motor may have failed to engage before the oven reached cleaning temperature.
4. On ProBake Convection models, the heating element is at the rear rather than the bottom. If the convection fan stopped, localized overheating near the rear element triggers the sensor. Check the fan motor.

Part cost: Temperature sensor/RTD probe (MEE62002708) $15–$35. Door latch assembly (ABA74268301) $35–$65. Professional repair: $160–$340.

F3 — Open Oven Temperature Sensor

The control board detects an open circuit in the temperature sensor wiring — the sensor is disconnected or its element has fractured.

Common causes:

• Sensor mounting screws loosened from thermal expansion cycling (part MEE62002708)
• Wire harness break at the oven insulation pass-through or cabinet rear wall (part EAD63928906)
• Sensor platinum element fractured from thermal stress — works at room temp but opens at operating temp
• Connector pulled loose during cleaning or rack adjustment

How to fix:

1. Verify the oven temperature sensor is securely mounted in the rear wall of the oven cavity. The mounting screws loosen from thermal expansion cycling.
2. Check the sensor wire connection at the control board — pull the oven away from the wall and access the rear panel.
3. Test resistance from the control board connector (disconnected) — at room temperature expect approximately 1,080 ohms. Open circuit confirms a broken sensor or wire.
4. Trace the sensor wiring for breaks where it passes through the oven insulation and cabinet rear wall.
5. Flex the sensor wire gently while monitoring resistance with a multimeter. An intermittent open indicates a fractured conductor inside the insulation.

Part cost: Temperature sensor/RTD probe (MEE62002708) $15–$35. Sensor wire harness (EAD63928906) $20–$40. Professional repair: $120–$230.

F9 — Door Lock Error

The oven door lock mechanism failed to engage or disengage properly, typically during or after a self-clean cycle.

Common causes:

• Lock motor failure or worn gear (part EBF61215205)
• Lock switch contacts worn (part 6600JB3007B)
• Oven still too hot for the lock to release (above 400°F threshold)
• Lock motor plastic gears degraded from frequent self-clean use
• Manual release lever jammed

How to fix:

1. Wait for the oven to cool below 400°F — the door lock will not disengage if the cavity temperature is above the safe threshold.
2. Listen for the lock motor attempting to engage when self-clean is selected. Grinding or clicking indicates a worn motor or broken gear.
3. If the door is stuck locked after self-clean, unplug the oven and manually release the latch using the manual release lever (accessible from the top of the oven behind the control panel).
4. Check the lock switch contacts — the door lock assembly has two micro-switches that signal locked/unlocked position.
5. Test the lock motor by applying 120V directly to its leads (disconnected from the board) — the latch arm should extend smoothly.

Part cost: Door lock assembly (ABA74268301) $35–$65. Lock motor (EBF61215205) $25–$45. Lock switch set (6600JB3007B) $10–$20. Professional repair: $140–$270.

F11 — Communication Error

The display/UI board and the relay/power board have lost serial communication. On double ovens, this means one cavity cannot receive commands.

Common causes:

• Ribbon cable or wire harness between boards damaged (part EAD63928907)
• Power surge latching up the communication controller IC
• Cold solder joints from years of thermal cycling
• Display board communication transceiver failure (part EBR84433508)
• Relay/power board failure (part EBR84433509)

How to fix:

1. Power cycle the oven by turning off the circuit breaker for 10 minutes. Communication bus errors can clear on full reset — this resolves approximately 40% of F11 cases.
2. On double ovens and combination units, F11 indicates the upper and lower boards lost serial communication.
3. Check the ribbon cable or wire harness connecting the display board to the relay/power board. Reseat both connectors firmly.
4. Inspect for loose or corroded pins at the board connectors. Oven heat causes solder joints to develop cold cracks over years of thermal cycling.
5. If the cable and connectors are intact, swap boards one at a time to isolate which board has the failed communication transceiver.

Part cost: UI control board (EBR84433508) $120–$200. Relay/power board (EBR84433509) $100–$180. Communication wire harness (EAD63928907) $25–$50. Professional repair: $220–$420.

Additional LG Oven Error Codes

• F5 — Latch motor switch failure. The control board cannot determine the door lock position. Check the lock switch set and wiring. Often overlaps with F9 causes. Replace lock assembly (ABA74268301, $35–$65).
• F7 — Bake igniter not functioning (gas models). The igniter does not glow or does not reach sufficient temperature to open the gas valve. Test igniter resistance (should read 40–400 ohms). Replace igniter ($25–$50) and verify gas valve operation.
• F8 — Broil igniter not functioning (gas models). Same diagnostic as F7 but for the broil burner. Check the broil igniter and valve independently.
• F10 — Control board EEPROM error. The non-volatile memory on the control board is corrupted. Board replacement required (EBR84433508, $120–$200).

LG Oven Diagnostic Modes

1. Smart Diagnosis (Audio): Turn on the oven. Call LG support (1-800-243-0000). When instructed, press and hold the Bake button while holding your phone speaker to the control panel area. The oven transmits diagnostic data as audio.

2. LG ThinQ App Diagnosis: For WiFi-enabled models, open the ThinQ app, select your oven, and tap Smart Diagnosis. The app retrieves error history, sensor readings, and relay status.

3. Manual Test Mode: On most LG ranges, press and hold the Bake + Broil buttons simultaneously for 5 seconds with the oven powered on. The unit enters test mode, cycling through the bake element, broil element, convection fan, door lock motor, and temperature sensor readings. Monitor each component for activation.

Frequently Asked Questions

Q: My LG oven shows F1 — is it safe to use? A: No. F1 indicates loss of safety relay monitoring. The oven could potentially heat without user input. Turn off the circuit breaker immediately. On gas models, close the gas supply valve. Do not restore power until the control board is replaced by a qualified technician.

Q: Why does F0 appear after I run self-clean on my LG ProBake oven? A: Self-clean cycles generate significant steam and heat that can migrate behind the control panel and temporarily short the membrane keypad traces. Allow the control panel area to dry for 24 hours. If F0 persists after drying, the membrane has permanent damage and needs replacement. Limiting self-clean use to 2–3 times per year reduces this risk.

Q: My LG oven door is locked shut after self-clean. How do I open it? A: First, verify the oven has cooled below 400°F — the lock will not release when the cavity is above the safe threshold. If the oven is cool but the door remains locked, unplug the oven and locate the manual release lever accessible from the top of the oven behind the control panel (varies by model). If no manual release is accessible, the lock motor has failed and requires professional removal.

Q: How do I test the oven temperature sensor myself? A: Disconnect the sensor wire at the control board (pull the oven away from the wall first). Measure resistance with a multimeter. At room temperature (77°F), a good LG RTD sensor reads approximately 1,080 ohms. At 350°F it reads about 1,300 ohms, and at 550°F about 1,500 ohms. An open circuit reading or a reading far outside these values confirms sensor failure. The part (MEE62002708) costs $15–$35.

Q: Is it worth repairing an LG oven control board or should I replace the oven? A: A control board replacement on an LG oven typically costs $250–$420 including parts and labor. If the oven is under 8 years old and has no other issues, the repair is cost-effective. If the board has failed multiple times, or if additional components (elements, lock, sensors) also need replacement, the cumulative repair cost may approach 50% of a new unit — the standard replacement threshold.

When to Call a Professional

These LG oven errors require professional diagnosis:

• F1 — Safety relay loss — Do not operate the oven at all. The relay protection circuit prevents uncontrolled heating. A stuck relay is a fire hazard.
• F2 with over-temperature — If the oven overheated, do not open the door. Allow 2+ hours of cooling. A stuck heating relay or failed sensor caused uncontrolled heating that needs professional diagnosis.
• F11 on double ovens — Communication bus faults between two control boards require board-level testing equipment to isolate the failed component.
• Gas models (F7, F8) — Gas igniter and valve repairs involve natural gas lines. If you smell gas, evacuate and call your gas utility.
• F2 with locked door — If the door is locked and the oven overheated, do not force the door open. The lock mechanism, temperature sensor, and control board may all need evaluation.
