How to Replace the Thermistor (Temperature Sensor) on a KitchenAid Dishwasher

The thermistor (temperature sensor) in a KitchenAid dishwasher monitors water temperature throughout the cycle. It tells the control board when water is hot enough to begin washing, when to activate the heating element, and when the heated dry phase is complete. When the thermistor fails, the most common symptoms are error code F3E1, cycles running excessively long (the board keeps heating indefinitely because it never reads the target temperature), or cycles ending prematurely without reaching proper wash temperature.

This is a small, inexpensive component (typically $10-$25) that clips onto the sump housing. The repair itself takes 20-30 minutes and requires basic access underneath the unit through the kick plate. KitchenAid uses the same thermistor design as Whirlpool since both share the same control platform.

Before You Start

• Tools needed: 1/4" hex nut driver (kick plate), Torx T20 or Phillips (mounting), multimeter, needle-nose pliers, towels
• Parts needed: Thermistor/temperature sensor (~$10-$25). Match to your model number
• Time required: 20-30 minutes
• Difficulty: Beginner to Intermediate
• Safety warning: Disconnect power at the circuit breaker before testing or replacing the thermistor. The sensor itself is a low-voltage component, but it connects to the control board and is located near 120V wiring.

How the KitchenAid Thermistor Works

The thermistor is a Negative Temperature Coefficient (NTC) resistor. Its resistance decreases as temperature increases. At room temperature (72F/22C) it typically reads 40,000-60,000 ohms. At wash temperature (130-140F/55-60C) it reads approximately 5,000-10,000 ohms. The control board monitors this resistance to determine water temperature.

When the thermistor fails:

• Open circuit (infinite resistance): Board reads no temperature data. Triggers F3E1 error. May prevent cycle from starting
• Shorted (near zero resistance): Board reads extremely high temperature. May skip heating entirely, resulting in cold wash
• Drifted (incorrect but stable reading): Board misinterprets temperature. Cycles run too long or too short

Confirming Thermistor Failure

Test 1: Check for Error Code F3E1

If your KitchenAid displays F3E1, the control board detected a thermistor circuit problem. This is the primary diagnostic indicator.

Test 2: Resistance Test

1. Disconnect power at breaker
2. Remove kick plate (two 1/4" hex screws)
3. Locate the thermistor on the sump housing (small probe with 2 wires)
4. Disconnect the wire connector
5. Measure resistance across the thermistor leads:
   • At room temperature: 40,000-60,000 ohms (model-specific; check tech sheet)
   • Open (OL): Thermistor failed open, replace
   • Less than 1,000 ohms at room temp: Shorted, replace

Test 3: Warm Water Test

If the room temperature reading is in range but you suspect drift, heat a cup of water to approximately 130F (use a kitchen thermometer). Hold the thermistor probe in the water (disconnect from dishwasher first). Resistance should drop to 5,000-10,000 ohms. If it stays high or drops to near zero, the thermistor has failed.

Step-by-Step Instructions

Step 1: Disconnect Power

Turn off the circuit breaker for the dishwasher. Confirm no display lights are on.

Step 2: Remove the Kick Plate

Remove the two 1/4" hex screws at the lower front. Pull panel forward and down.

Step 3: Locate the Thermistor

The thermistor is a small cylindrical or oval-shaped probe that clips into the sump housing on the underside of the tub. It is positioned where circulating water flows past it during operation. On most KitchenAid/Whirlpool-platform dishwashers, it is on the right side of the sump, near where the sump connects to the tub.

It has a 2-wire connector (usually small plug style, not spade terminals).

Step 4: Disconnect the Wire Connector

Press the locking tab on the connector and pull straight out. The connector is small; needle-nose pliers help if your fingers cannot reach the tab.

Step 5: Remove the Old Thermistor

The thermistor is typically held by a retaining clip or pushed into a rubber grommet in the sump wall. For clip-mounted: squeeze the clip tabs and pull the sensor probe out. For grommet-mounted: pull the sensor straight out of the grommet. Some resistance is normal from the rubber seal.

Step 6: Install the New Thermistor

Push the new sensor probe into the same mounting hole until it clicks (clip type) or seats fully in the grommet. The sensor tip must be inside the sump where it contacts circulating water during operation. If it is not inserted far enough, it reads air temperature instead of water temperature.

Step 7: Reconnect the Wire Connector

Plug the connector back in until the locking tab engages. Verify it is fully seated.

Step 8: Test the Repair

Restore power. The F3E1 error should clear. Run a Normal cycle. Monitor cycle duration. A normal KitchenAid cycle runs 45-90 minutes depending on soil level (ProWash adjusts). If the cycle length is now normal and dishes come out hot/dry, the repair is successful.

Troubleshooting After Replacement

• If F3E1 persists with a new thermistor, check the wire harness for damage between the sensor and control board. A chafed wire touching ground can create an erroneous reading
• If cycles still run excessively long, the heater element may be failing to heat water (separate issue). Test heater resistance (10-30 ohms normal)
• If the dishwasher now cuts cycles short (dishes not fully clean/dry), the new thermistor may be reading high. Verify correct part number for your model
• If multiple temperature-related errors appear (F3E1 + F3E2), the control board sensor input circuit may be damaged

Thermistor vs. Heater: Which Has Failed?

When to Call a Professional

• The thermistor itself is a simple, cheap replacement. Call a professional only if the error persists after replacement, indicating a control board or wiring issue
• If you cannot locate the thermistor (some panel-ready models have access constraints), a technician familiar with the model can identify it quickly
• If water damage is visible around the sump area where the thermistor mounts, the sump may need inspection for leaks

Cost Comparison: DIY vs Professional

Need Professional Help?

• dishwasher repair service
• kitchenaid appliance repair
• dishwasher repair cost guide

FAQ

Q: What does error code F3E1 mean on a KitchenAid dishwasher? A: F3E1 indicates a thermistor (temperature sensor) circuit failure. The control board cannot read water temperature. This is the same error code used across all Whirlpool-platform dishwashers. Replace the thermistor to resolve.

Q: Why does my KitchenAid dishwasher cycle take 3+ hours? A: Excessively long cycles usually mean the thermistor is reading incorrectly, telling the board that water never reaches target temperature. The board keeps heating and waiting. Replace the thermistor. If cycles are still long after, the heater element may be failing to actually heat the water.

Q: Can a bad thermistor damage my KitchenAid dishwasher? A: A thermistor reading low (telling the board water is cold when it is actually hot) can cause the heater to run continuously until thermal safety limits trip. This excessive heating can shorten heater life and stress seals. Replace promptly when F3E1 appears.

Q: Where exactly is the thermistor located in a KitchenAid dishwasher? A: It clips into the sump housing underneath the tub, accessible from below after removing the kick plate. Look for a small cylindrical probe with a 2-wire connector on the right side of the sump area. The probe tip sits inside the sump where circulating water contacts it.

---
