How to Replace a Samsung Ice Maker Assembly

Samsung ice makers are one of the most commonly replaced refrigerator components across all Samsung models — from RF-series French door to RS-series side-by-side units. The fundamental design flaw (defrost drain freezing) combined with the thermal stress of repeated freeze-thaw cycles makes the ice maker a wear item that typically needs replacement every 3-5 years on affected models.

This guide provides a universal approach covering both French door and side-by-side Samsung refrigerators. The core procedure is identical: remove one Phillips screw, disconnect one wire harness, disconnect one water line, and reverse with the new unit. Samsung designed their ice makers for relatively easy service access.

Before You Start

• Tools needed: Phillips #2 screwdriver (Samsung's universal fastener), needle-nose pliers, towels, hair dryer if ice present
• Parts needed: Samsung ice maker assembly (DA97-series, model-specific — verify via your model number on Samsung Parts), drain strap kit DA82-02367A (strongly recommended for French door models)
• Time required: 25-40 minutes
• Difficulty: Intermediate
• Safety warning: Unplug the refrigerator and turn off the water supply shutoff valve before beginning.

Step-by-Step Instructions

Step 1: Turn off water and disconnect power

Close the water shutoff valve behind or beneath the refrigerator (turn clockwise until fully closed). Unplug the refrigerator from the wall outlet. Open the freezer compartment and remove the ice bucket by pressing release tabs and pulling straight out. Discard any remaining ice.

Step 2: Access the ice maker

On Samsung French door models, the ice maker is visible once the ice bucket is removed — it sits at the top of the freezer compartment above where the bucket was. On side-by-side models, open the freezer door and locate the ice maker mounted to the ceiling or upper rear wall of the freezer section.

Step 3: Disconnect the wire harness

Locate the wire harness connector on the side of the ice maker (usually left side). Press the plastic locking tab and pull the connector straight apart. Never pull on the wires themselves. Some models have a second smaller connector for a temperature sensor — disconnect that as well if present.

Step 4: Remove the mounting screw

Samsung ice makers use a single Phillips #2 screw on the left mounting bracket. Remove this screw. The ice maker hangs on hooks at the rear. Lift the front edge slightly upward and pull forward to release from the hooks. On some side-by-side models, there are 2 screws — one on each side.

Step 5: Disconnect the water fill tube

The water fill tube connects to the rear of the ice maker via a quick-connect or push-in fitting. For quick-connect: press the release collar and pull the tube free. For push-in fittings: pull the retaining clip out, then pull the tube. Have a towel ready — residual water will drip.

Step 6: Install drain strap kit DA82-02367A (French door models)

With the ice maker removed, you have clear access to the drain area. On French door models, install the drain strap now to prevent the ice buildup that likely caused the original failure. Clip it to the defrost heater at its closest point to the drain opening and extend the lower tab into the drain hole.

Step 7: Mount the new ice maker

Connect the water fill tube to the new assembly first (push into quick-connect until it seats past the O-ring). Position the ice maker on the rear hooks, then pivot the front down into position. Secure with the Phillips #2 mounting screw(s). Connect the wire harness until the locking tab clicks.

Step 8: Restore utilities and initial operation

Turn the water supply back on. Check for leaks at the fill tube connection. Plug in the refrigerator. Enable the ice maker via the display panel or SmartThings app. The Samsung inverter compressor will click briefly at startup (normal). First ice production begins once the freezer reaches 0 degrees F — expect ice in 6-8 hours. Discard the first two batches.

Troubleshooting Common Issues

• No ice production after 12 hours: Verify ice maker is enabled in settings. Check fill tube for ice blockage (hair dryer to thaw). Confirm water supply valve is fully open. Run forced defrost if needed (Energy Saver + Fridge, 8 seconds)
• Tiny or hollow ice cubes: Low water pressure (Samsung requires 20 PSI minimum) or clogged DA29-series water filter. Replace filter and check household water pressure
• Motor runs but cubes stick in mold: Wire harness partially connected, preventing the mold heater from receiving power. Disconnect and firmly reconnect until click is felt
• Error code 8E or 14E after installation: Unplug for 5 minutes to reset the control board. If error persists, check the sensor connector (second smaller plug if your model has one)
• Water leaks from fill tube area: Quick-connect not fully seated. Turn off water, remove tube, and reinsert with firm pressure until it passes the internal O-ring

When This Fix Will Not Work

Contact a professional if:

• The compressor is not running (no cooling at all), meaning the freezer cannot reach the temperature needed for ice production — this is a separate compressor or sealed-system issue
• The water supply line inside the cabinet is cracked or corroded, requiring internal line replacement
• Your Samsung model uses a non-standard ice maker with different mounting (rare but exists on some specialty models)
• The unit is within Samsung's 1-year standard warranty — have Samsung service perform the repair under warranty

Cost Comparison: DIY vs Professional

Need Professional Help?

• refrigerator repair service
• samsung appliance repair
• refrigerator repair cost guide

FAQ

Q: How do I find the correct part number for my Samsung ice maker? A: Find your model number on the sticker inside the fresh food compartment (left wall on French door, side wall on side-by-side). Enter it at samsungparts.com or search for your model + "ice maker assembly" for the correct DA97-series number.

Q: Is it worth replacing the ice maker or should I buy a new refrigerator? A: At $80-160 for the part plus the $8-15 drain strap, ice maker replacement is highly cost-effective. A new Samsung refrigerator costs $1,500-3,500. Replace the ice maker and install the drain strap for a lasting fix.

Q: Will the new ice maker have the same freezing problem? A: Without the drain strap kit DA82-02367A installed, yes — the same design flaw will eventually damage the new assembly. Always install the drain strap during replacement to prevent recurrence.

Q: Can I install a non-Samsung ice maker in my Samsung refrigerator? A: Third-party ice makers exist but have compatibility issues with Samsung's control boards and may produce different-sized cubes. Samsung OEM assemblies (DA97-series) are recommended for reliability and proper fit.

---
