Kenmore Elite 110/796 Dryer (Whirlpool-made)

Because this series runs on the Whirlpool platform, element and thermal-fuse replacements cost less than a single service call from many competitors, which tilts most repair decisions toward fixing rather than replacing. This guide lays out the covered models, ranked failures, the full code list, the OEM parts that wear out, and current recall status.

Model Specifications#

All five share the Whirlpool platform, one parts catalog, and the same failure modes, so a repair proven on one applies to the rest. Feature highlights include Steam Refresh, the AccuDry moisture sensor, Wrinkle Guard, and Energy Star certification.

Common Problems for This Model#

Ordered by how often they appear, with the symptom and the fix:

1. Heating element burning out (25%) — the dryer runs but produces no heat. The element (part WP3387747) is a direct-replacement part and the first thing to test when the drum turns cold.
2. Thermal fuse blowing from restricted venting (20%) — the dryer stops heating or will not start. The fuse (WP3392519) is cheap, but it blows because the vent is choked, so clear the duct before fitting the new one.
3. Drum roller bearings wearing out (15%) — a thumping or squealing noise develops. The four-roller kit (WP4581EL3001 or 4581EL2002C) restores quiet running.
4. Belt snapping (10%) — the drum will not turn while the motor keeps running. The belt (6602-001655) is replaced with the cabinet open.
5. Gas valve coils failing intermittently on gas models (8%) — the heat cuts in and out. The coil set (WP279834) is swapped as a pair.

Error Codes#

This platform is unusually talkative; the panel can display any of:

• F01, F22, F23, F26, F28, F30, F31, F70

For a code outside this list, unplug the dryer or flip the breaker for 60 seconds and restore power to clear transient faults. A code that returns immediately marks a hardware failure for diagnosis.

Parts That Commonly Fail#

Always confirm the number against your exact model, since production years vary:

Recall Status#

There are no active recalls on the Kenmore Elite 110/796 series as of 2026-05-28. Since a recall can land at any time, check the Consumer Product Safety Commission at cpsc.gov against your model number and subscribe to their email alerts.

Repair or Replace?#

Three inputs drive the choice: unit age, repair cost, and total spend to date. Under 10 years old with a fix below 50% of a new equivalent, repair is the clear winner, and it is especially clear here because the Whirlpool parts are so cheap. Past 10 years, add up the last two to three years of repairs; once that clears 40% of replacement cost, a new unit with a fresh warranty makes more sense. Expected service life on this platform runs 12 to 15 years.

Maintenance That Prevents These Failures#

• Clean the lint filter after every load.
• Clean the full vent duct from dryer to exterior every year; restricted vents are the number-one cause of thermal-fuse failure.
• Vacuum the lint-trap housing with a narrow attachment every 6 months.
• Check the exterior vent flap for bird nests or lint buildup.
• If the dryer needs more than one cycle to dry, the vent is restricted; clear it before the fuse blows.

A restricted exhaust vent is the number one cause of both poor drying performance and dryer fires, so treat slow drying as a venting problem first and a component fault second.
