How to Replace a Frigidaire Dryer Heating Element

Frigidaire dryers give easy rear access to the element housing, unlike some brands that need full disassembly. The element slides out of its housing after you remove the rear access panel and disconnect 2 wires, making this one of the most straightforward Frigidaire dryer repairs.

Tools, Parts, and Safety First#

• Tools needed: Phillips #2 screwdriver, 1/4-inch nut driver, multimeter
• Parts needed: Heating element assembly (varies by model-specific — match wattage)
• Time required: 20-30 minutes
• Difficulty: Beginner
• Safety warning: Unplug the dryer. Element terminals carry 240V during operation. Wait 5 minutes after unplugging before touching terminals (capacitor discharge).

Step-by-Step Instructions#

Step 1 — Diagnose the element#

With the dryer unplugged, remove the rear element access panel (4-6 screws — this is a separate small panel, not the whole rear). Find the element housing, a metal box or channel with 2 wires connected. Disconnect one wire from the element (so you do not read through other circuits) and meter across both terminals: 10-50 ohms means the element is intact (not the problem), while infinite/OL means the coil is broken (replace it). Then test each terminal to the element housing/ground: no continuity is normal (the element is insulated from the housing), but any continuity means a grounded element (the coil is touching the housing — replace immediately).

Step 2 — Remove the element housing#

Disconnect both wires from the element terminals, remove the mounting screws or bracket holding the housing (typically 1-2 screws), and slide the element assembly straight out of its compartment.

Step 3 — Transfer any reusable components#

Some Frigidaire element assemblies include the housing, while others are just the element (coil plus frame) that inserts into your existing housing. If your replacement is element-only, remove the old coil assembly from the housing (it slides or clips out) and insert the new one. Verify the new element's wattage matches the original — an overpowered element causes overheating and premature thermal-fuse failure.

Step 4 — Install the new element#

Slide the new element housing (or element-in-housing) into the compartment and secure it with the mounting screws. Reconnect both wires to the element terminals — each is a push-on (spade) connector, so push firmly until seated.

Step 5 — Clean the exhaust path#

Before reassembly, clear the lint from inside the dryer around the element area. A clogged exhaust makes the element overheat, which causes the coil to sag, which causes grounding or premature failure, so clean the blower housing and exhaust vent while you have access.

Step 6 — Test#

Replace the access panel, plug in, and run a timed-dry cycle on high heat. The dryer should produce strong heat within 2-3 minutes, and hot air should be flowing at the exterior vent. If there is no heat, verify both breaker poles are on — losing one leg leaves the motor running but no heat at 240V.

Troubleshooting Common Issues#

• New element glows red but the dryer still does not dry: the element works but airflow is restricted — clean the exhaust vent, blower housing, and lint-trap path.
• Breaker trips with the new element: check element-to-ground continuity, since even new elements can be defective, and verify the wattage match (an overpowered element draws overcurrent).
• Element burns out again within months: an exhaust restriction is causing overheating, so the vent path MUST be clear — and check the cycling thermostat, since if it fails to cycle the element off at the set temperature, the element runs continuously and overheats.

When Should You Call a Professional?#

EasyBear technicians serving Sacramento and the Bay Area carry Frigidaire-specific diagnostic tools and replacement parts on every service call. Call one if the breaker keeps tripping despite a new element testing good (the wiring inside the dryer may have heat damage), if the element compartment shows signs of arcing or fire damage, or if you are not comfortable working with 240V circuit components.
