Whirlpool WRS571 Refrigerator — Issues & Fixes

A counter-depth cabinet gives a built-in look but leaves less room behind the condenser, so this model's leading complaint is a condenser working harder in warm kitchens, followed by dispenser and filter issues. Below are the covered models, the ranked problems, the code it reports, and a repair-or-replace framework.

Model Specifications#

All three variants share one platform and parts catalog. The line features an in-door pizza pocket, frameless glass shelves, Accu-Chill temperature management, and an external ice and water dispenser.

Common Problems for This Model#

Ranked by field frequency, with the symptom and the fix:

1. Counter-depth condenser runs hotter (16%) — the compressor works harder in a warm kitchen with the tighter rear clearance. Cleaning the coils and ensuring clearance keeps it in check.
2. Ice dispenser chute flap sticks open (14%) — warm air enters the freezer and frost forms on the ice. The chute flap is freed or replaced.
3. Water filter bypass plug leaks after a filter change (10%) — a damaged O-ring drips. The bypass plug or O-ring is replaced.
4. LED control board on the dispenser panel fails (8%) — the display goes dark. The dispenser LED board is replaced.

Error Codes#

The WRS571 can display this code:

• CF

For a code outside this, cut power at the plug or breaker for 60 seconds and restore it to clear transient faults. A code that returns immediately needs a proper diagnosis.

Before You Call for Service#

A few checks resolve common WRS571 complaints before a visit:

• If the fridge struggles in a warm kitchen, clean the condenser coils and confirm at least an inch of rear clearance, which addresses the top fault directly.
• If frost forms on the ice or the freezer, check that the ice-chute flap is closing fully.
• If water drips after a filter change, inspect the bypass plug O-ring, which is easily nicked during the swap.
• Try a hard reset by unplugging for a minute before assuming an electronic fault.

Recall Status#

There are no active recalls on the Whirlpool WRS571 series as of 2026-05-28. Because a recall can be issued at any time, check the Consumer Product Safety Commission at cpsc.gov with your model number and sign up for their email alerts.

Repair or Replace?#

Weigh the age of the unit, the cost of the fix, and its cumulative history. Under 10 years old with a repair below 50% of a comparable new refrigerator, repair is the better value, and most WRS571 faults are inexpensive parts or simple maintenance. After 10 years, add up the last two to three years of repairs; once that exceeds 40% of replacement cost, a new unit with a fresh warranty is the smarter move. A sealed-system or compressor fault is the main case that tips toward replacement on a unit this age.

Long-Term Ownership Tips#

Because a counter-depth body runs its condenser in tighter clearances, keeping the coils clean every 6 months and holding at least an inch of rear clearance matters more here than on a standard-depth fridge, especially in a kitchen that runs warm. Hold the fresh-food side near 37°F and the freezer near 0°F, replace the water filter every 6 months, and inspect the bypass plug O-ring whenever you change a filter. These habits head off the condenser and dispenser faults that lead this model's repair list.
