KitchenAid KRFC704 Refrigerator Guide

Because a counter-depth cabinet trades interior depth for a flush, built-in look, it runs its condenser in tighter clearances than a standard fridge, which shapes this model's fault list. On top of that it carries the Whirlpool-platform ice-maker frost issue and a Preserva dual-evaporator cooling system. Below are the covered models, the ranked problems with the part behind each, the codes it reports, and a repair-or-replace framework.

Model Specifications#

All four variants share one platform and parts catalog. The line features ExtendFresh Plus temperature management, Preserva Food Care with dual independent cooling, a Platinum interior, an under-shelf prep zone, a Measured Fill dispenser, and a PrintShield finish.

Common Problems for This Model#

Ranked by field frequency, each with the part behind it:

1. Ice maker frost buildup and shutdown (22%) — the common Whirlpool-platform fault. The ice maker assembly (WPW10377151) addresses it.
2. Preserva dual evaporator fan-motor failure (14%) — one compartment loses cooling while the other holds. The evaporator fan motor (WPW10189703) is replaced.
3. Counter-depth condenser coil overheating (12%) — the shallow body restricts airflow around the condenser. The condenser fan motor (WPW10310240) and a coil cleaning restore it.
4. Measured Fill dispenser solenoid sticking (10%) — it overfills or will not stop. The Measured Fill solenoid (W10862040) is the fix.
5. Main control board relay failure (8%) — the compressor short-cycles. The main control board (W10503278) carries the failing relay.

Error Codes#

The panel can display any of these codes:

• PO
• DOOR AJAR
• CF

For a code outside this list, unplug the refrigerator or trip the breaker for 60 seconds and restore power to clear transient faults. A code that returns immediately needs a proper diagnosis.

Parts That Commonly Fail#

Match each number to your exact model before ordering:

Recall Status#

There are no active recalls on the KitchenAid KRFC704 series as of 2026-05-28. Because a recall can be issued at any time, check the Consumer Product Safety Commission at cpsc.gov with your model number and sign up for their email alerts.

Repair or Replace?#

Counter-depth refrigerators are premium units that need a precise cabinet fit, so replacing one is more involved than swapping a standard fridge, and that tilts the KRFC704 toward repair. Under 10 years old with a fix below 50% of a new equivalent, repair is the clear value. After 10 years, add up the last two to three years of repairs; only once that clears 40% of replacement cost does the built-in fit make replacement worth the disruption.

Before You Call for Service#

A few checks resolve common KRFC704 complaints before a visit:

• For frost or weak cooling, replace the water filter and manually defrost the ice-maker zone first.
• If one compartment warms while the other stays cold, suspect the Preserva evaporator fan rather than the whole system.
• If the fridge runs hot or short-cycles, clean the condenser coils, which a counter-depth body needs more often, and confirm at least an inch of rear clearance.
• If the dispenser overfills, clean the Measured Fill nozzle before assuming a solenoid fault. Hold the compartment near 37°F and the freezer near 0°F.
